Belden-5202UE Price in Riyadh, Saudi Arabia
Belden 5202UE is a 4-conductor, 16 AWG, unshielded, riser-rated (CMR) cable designed for low-voltage applications such as security systems, intercom/public address (PA) systems, audio/speaker connections, and power-limited control circuits. Its construction includes stranded bare copper conductors, polypropylene insulation, and a PVC jacket with a ripcord, making it suitable for indoor installations requiring CMR compliance.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
11
People watching this product now!
Payment Methods:
Description
| Property | Details |
|---|---|
| Cable Type | Multi-Conductor, Unshielded |
| Conductor Material | Stranded Bare Copper (19×29) |
| Conductor Size | 16 AWG |
| Number of Conductors | 4 |
| Insulation Material | Polypropylene (PP) |
| Insulation Thickness | 0.008 in (0.20 mm) |
| Insulation Diameter | 0.073 in (1.9 mm) |
| Color Code | Black, Red, White, Green |
| Jacket Material | PVC (Polyvinyl Chloride) |
| Jacket Thickness | 0.017 in (0.43 mm) |
| Outer Jacket Diameter | 0.205 in (5.21 mm) |
| Jacket Color | Gray |
| Ripcord | Yes |
| Voltage Rating | 300V |
| Temperature Rating | -20°C to +75°C |
| Flame Rating | UL 1666 Riser, FT4, IEC 60332-1-2 |
| Conductor DCR | 4.2 Ohm/1000 ft |
| Capacitance (Cond-Cond) | 23 pF/ft (75 pF/m) |
| Max. Current | 5.0 Amps per conductor @ 25°C |
| Bend Radius (Installation) | 2.1 in (53 mm) |
| Max. Pull Tension | 117 lbs (53.1 kg) |
| Bulk Cable Weight | 42 lbs/1000 ft |
| Compliance Standards | NEC Article 800, CMR; CEC CMG; RoHS; CE; UKCA; China RoHS II |
| Applications | Security systems, intercom/PA, audio/speaker, power-limited controls |
